Product Introduction

PVC Double Sockets Tee with Flanged Branch is hot-sale product in the market.It is used for jointing the PVC pipes.If you have any question about PVC Double Sockets Tee with Flanged Branch, please contact us.

PVC Double Sockets Tee with Flanged Branch is mainly used to connect PVC pipes. The main material is ductile iron, which is very strong and resistant to wear and tear. The surface is usually galvanized and painted with special treatment. It is available in sizes DN63-400mm, with a full range of specifications to meet a variety of needs. Also, we can customize special sizes for customers who need them.

Features

PVC Double Sockets Tee with Flanged Branch is the first choice for customers to choose similar products because of its reliable quality and favorable price. Its inner wall is also polished and sized, which is very smooth, making the resistance to fluid low and the water flow stable. In addition, it has good resistance to water pressure, external pressure and impact, which makes it suitable for piping projects under various conditions.

More Info.

1. Materials & Relevant Standards

MATERIAL:

Ductile iron grade 500-7/ 450-12 in accordance with ISO 1083.

GASKET: Rubber E.P.D.M. in accordance with EN 681.1

WORKING PRESSURE: 16 Bar or 250 PSI.

FLUID TEMPERATURE: 0°C-50°C， excluding frost.

2. COATING:

External coatings:

1) Zinc coating +bitumen painting

2) Liquid epoxy painting

3) Fusion bonded epoxy applied

4) According to customers' requirements

Internal coatings:

1) Zinc coating +bitumen painting

2) Liquid epoxy painting

3) Fusion bonded epoxy applied

4) According to customers' requirements

3. REFERENCE RULES:

Dimensions and testing in accordance with BSEN 12842.

USE:

Used for joining the PVC pipes, they can be assembled by pushing the spigot through the gasket in the socket of the mating component.

Specification

OD	dn	L	H	Mass (kg)		T	e	E	X
OD	dn	L	H	PN10	PN16	T	e	E	X
63	50	70	140	5.89	5.89	6.2	6.2	57	239
63	60/65	80	140	6.78	6.78	6.2	6.2	57	249
75	50	70	140	6.52	6.52	6.5	6.5	68	247
75	60/65	85	140	7.50	7.50	6.5	6.5	68	262
90	50	75	145	7.60	7.60	6.8	6.8	83	266
90	60/65	90	155	8.72	8.72	6.8	6.8	83	281
90	80	105	160	9.54	9.54	6.8	6.8	83	296

110	50	75	145	9.40	9.40	7	6.5	102	279
110	60/65	90	165	10.10	10.10	7	7	102	294
110	80	105	170	10.95	10.95	7	7	102	309
110	100	125	170	12.21	12.21	7	7	102	329

125	60/65	90	160	11.11	11.11	7.2	7	116	303
125	80	105	170	12.05	12.05	7.2	7	116	318
125	100	125	180	13.53	13.53	7.2	7.2	116	338
125	125	150	180	15.40	15.40	7.2	7.2	116	363

140	60/65	90	180	12.72	12.72	7.5	7	130	314
140	80	105	185	13.64	13.64	7.5	7	130	329
140	100	125	195	15.18	15.18	7.5	7.2	130	349
140	125	150	200	17.34	17.34	7.5	7.5	130	374

160	50	75	170	13.34	13.34	7.8	7	150	313
160	60/65	90	190	14.77	14.77	7.8	7	150	328
160	80	105	200	15.84	15.84	7.8	7	150	343
160	100	125	205	17.38	17.38	7.8	7.2	150	363
160	125	150	210	19.50	19.50	7.8	7.5	150	388
160	150	175	220	22.47	22.47	7.8	7.8	150	413

200	60/65	125	215	19.98	19.98	8	7	189	385
200	80	140	225	21.18	21.18	8	7	189	400
200	100	160	230	22.91	22.91	8	7.2	189	420
200	125	185	240	25.37	25.37	8	7.5	189	445
200	150	210	245	28.67	28.67	8	7.8	189	470
200	200	260	250	34.82	34.73	8	8	189	520

225	40	100	195	21.30	21.30	8.2	7	213	377
225	50	110	195	21.70	21.70	8.2	7	213	387
225	60/65	125	215	23.05	23.05	8.2	7	213	402
225	80	140	225	24.31	24.31	8.2	7	213	417
225	100	160	230	26.07	26.07	8.2	7.2	213	437
225	125	185	240	28.71	28.71	8.2	7.5	213	462
225	150	210	245	31.97	31.97	8.2	7.8	213	487
225	200	260	260	38.42	38.32	8.2	8.2	213	537

250	60/65	140	250	27.83	27.83	8.5	7	237	417
250	80	155	250	29.15	29.15	8.5	7	237	450
250	100	175	255	31.13	31.13	8.5	7.2	237	470
250	125	200	260	33.77	33.77	8.5	7.5	237	495
250	150	225	265	37.25	37.25	8.5	7.8	237	520
250	200	275	275	43.92	43.82	8.5	8.4	237	570
250	250	325	285	52.54	52.10	8.5	8.5	237	620

315	60/65	140	290	38.78	38.78	9	7	300	477
315	80	155	295	40.37	40.37	9	7	300	492
315	100	175	300	42.74	42.74	9	7.2	300	512
315	125	200	305	45.91	45.91	9	7.5	300	537
315	150	225	310	49.50	49.50	9	7.8	300	562
315	200	275	310	56.20	55.97	9	8.4	300	612
315	250	325	310	64.40	64.02	9	9	300	662
315	300	375	310	73.20	72.82	9	9	300	712

400	80	210	340	62.00	62.00	10	7	385	559
400	100	210	355	66.00	66.00	10	7.2	385	594
400	150	275	360	75.60	75.60	10	7.8	385	659
400	200	325	365	83.80	83.60	10	8.4	385	709
400	250	370	375	93.40	93.00	10	9	385	754
400	300	420	385	104.20	103.80	10	9.6	385	804
400	400	520	395	125.50	129.80	10	10	385	904

Why Choose Us?

1. Our factory have more 20-year experience OEM DI pipe fitting for Europe and U.S.A high-end market

2. More than 5000 type pipe fitting patterns are used in my factory.

3. We have an automatic molding line, which suits large quantity production.

4. Our fitting according to EN545, ISO2531, AWWA C110&C153, EN12842 PVC fitting, Flange adaptor, Universal coupling, Express fitting, MECHANICAL JOINT FITTINGS and Philippines MJ fitting.

5. Factory Size:30,000-50,000 square meters.

FAQ

1. What's our process?

For fittings bigger than DN300, we use resin sand cast;

For fittings no bigger than DN300( including DN300), we use clay sand cast.

Greensand with hand molding and 3 semi-automatic lines are available.

For more detailed info, contact me, please.

2. Could we foundry customers' brands on castings?

Yes, both our brand "xinxing" and customers brand marked on products are acceptable.

3. Is third-party inspection is available for our castings?

Yes, both foundry in-house and third-party inspection are available.

While the third-party inspection may be bear by customers self.
